CIB-FCAN-MPE1

·Compliant with PCI Express 1.1
·Meet the Requirements of the ISO 11898- 1
·CAN bus 2.0B backward compatible with 2.0A
·Support baud rate 10/20/50/100/125/250/500/800/1000K
·Support CAN message acceptance filter
·Support Linux SocketCAN
·Support SAE J1939/CANopen high layer protocol (Optional)
·Termination resistor enabled/disabled by jumper
·Compliant with IEC 62368-1: 2020+A11: 2020
·Compliant with EN 6100-6-4+A1,CISPR 32, RE Class A
·Compliant with IEC 6100-4-2:2008 (ESD) Air ± 8 kV, Contact ±6kV , Criteria B
·Compliant with IEC 6100-4-4:2012 ，EFT/Burst:土2KV ，5/50ns，5/100Kz，Criteria B
·Compliant with IEC 6100-4-6:2003 ，CS: (0.15-230) MHz，10V， (1kHz.AM 80%)，Criteria A ·Compliant with IEC 61000-4-5:2014+A1:2017 , Surge : +1kv，line to earth, Criteria B
·Compliant with NECA TR-28/JEM-TR177 , Noise : 2000V.50ns、300ns、700ns、1000ns，Criteria B ·Temperature (-20°C to +60°C) support
