型号
基础信息

CIS-DSKL-FAR1（H110）

· 4U Rack-mount PC

· Intel® 6th/7th/8th/9th Generation Core™ /Pentium®/Celeron（up to 95W）, H110平台
· 2x DDR4 2133/2400/2666 MHz 288-pin DIMM, Max to 32GB
· VGA, HDMI and DVI-D
· 4x USB 3.2 (Gen1), 2x USB 2.0
· 1x PCIe x16 (Gen3), 1 x PCIe x4 (Gen2), 5x PCI
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open
· 1250W ATX Power MAX

CIS-DSKL-FAR1（Q170）

· 4U Rack-mount PC

· Intel® 6th/7th/8th/9th Generation Core™ /Pentium®/Celeron（up to 95W）, Q170平台
· 4x DDR4 2400/2666/2933 MHz 288-pin DIMM, Max to 64GB（16GB per DIMM）
· VGA, HDMI and DVI-D
· 4x USB 3.2 (Gen1)
· 1x PCIe x16 (Gen3), 2x PCIe x4 (Gen2), 3x PCI
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open

CIS-DCML-FAR1

4U Rack-mount PC

· Intel® 10th/11th Generation CoreTM /Pentium®/Celeron LGA 1151 Socket Processors with TDP up tp 125W
· DDR4 2666/2933 MHz 288-pin DIMM x4 Max to 128GB(32GB per DIMM)
· DP++, HDMI, VGA
· 4 x USB 3.2(Gen2), 2 x USB3.2(Gen 1),2× USB 2.0
· 2 x PCIe x16(Gen3), 2 x PCIe x 4(Gen3), 2 × PCle x 1(Gen1), 1×PCl
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open
· 1250W ATX Power MAX

CIS-DADL-FAR1（W680）

4U Rack-mount PC

· Intel® W680 Chipset
· Intel® 12th generation Core™ i9/i7/i5/i3/Pentium ®/Celeron® CPU
· Dual channel（Non-ECC）DDR4 3200 MHz up to 128GB
· VGA, HDMI and DP++
· 2 x PCIex16（Gen4） , 3 x PCIex4（Gen4）, 1 x PClex1（Gen3）, 1 x PCI;
· I/O slot: 2 x USB3.2（Gen2）, 2 x USB3.2（Gen1）, 4 x Intel LAN, 6 x COM
· 3.5 inches x4 Rigid Disk（SATA3.0）RAID 0, 1, 5, 10
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open
· USB self-rocovery, 5V/5VSB power optional

CIS-DADL-FAR1（H610）

· 4U Rack-mount PC

· Intel® H610 Chipset
· Intel® 12th/13th generation Core™ i9/i7/i5/i3/Pentium ®/Celeron® CPU
· Dual channel（Non-ECC）DDR4 3200 MHz up to 128GB
· VGA, HDMI and DP++
· 2x PCIe x16（Gen4） , 3x PCIe x4（Gen4）, 1x PCle x1（Gen3）, 1x PCI
· I/O slot: 2x USB3.2（Gen2）, 2x USB3.2（Gen1）, 4x Intel LAN, 6x COM
· 3.5 inches x4 Rigid Disk（SATA3.0）RAID 0, 1, 5, 10
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open

CIS-DADL-FAR1（Q670）

· 4U Rack-mount PC

· Intel® Q670 Chipset
· Intel® 12th/13th generation Core™ i9/i7/i5/i3/Pentium ®/Celeron® CPU
· Dual channel（Non-ECC）DDR4 3200 MHz up to 128GB
· VGA, HDMI and DP++
· 2x PCIe x16（Gen4） , 3x PCIe x4（Gen4）, 1x PCle x1（Gen3）, 1x PCI
· I/O slot: 2x USB3.2（Gen2）, 2x USB3.2（Gen1）, 4x Intel LAN, 6x COM
· 3.5 inches x4 Rigid Disk（SATA3.0）RAID 0, 1, 5, 10
· OS Recovery
· TPM Module
· 16-bit Programmable GPIO
· KB lock, Case open
